HF Setting

HF Setting#

Module Selection#

../../media/24NO230.png

2D Module Only#

../../media/24NO232.png

2D&RFID Module#

Output Format#

ASCII#

../../media/25RFIDFMT23HF0.png

* ASCII#

ASCII (LSB first)#

../../media/25RFIDFMT23HF5.png

ASCII (LSB first)#

Original (Hex)#

../../media/25RFIDFMT23HF2.png

Original (Hex)#

Decimal (MSB first)#

../../media/25RFIDFMT23HF3.png

2D&RFID Module#

Decimal (LSB first)#

../../media/25RFIDFMT23HF4.png

2D&RFID Module#

See also

For example, the output is E0:00:12:34

  • ASCII : E0001234

  • ASCII (LSB first): 341200E0

  • Original (Hex) : 0xE0,0x00,0x12,0x34

  • Decimal (MSB first): HEX2DEC(0xE0001234) = 3758101044

  • Decimal (LSB first): HEX2DEC(0x341200E0) = 0873595104
